Hydraulic system of truck mounted concrete pump:

1. Rexroth main oil pump and Rexroth valve group,.

2. Fully hydraulic control telescopic outrigger, easy to operate.

3. The hydraulic system adopts the starting circuit and electric reversing system, and is equipped with high and low pressure switching valve. The working state of the pump can be adjusted freely according to the construction requirements to facilitate the operation of the construction personnel.

Pumping system of truck mounted concrete pump:

1. The design of concrete conveying cylinder and long-distance master cylinder can meet the needs of different working conditions such as large displacement and long-distance transportation.

2. Spectacle plate, cutting ring, good, long service life.

3. High and low pressure automatic switching, with two working modes: low pressure large displacement and high pressure small displacement.

Control system of truck mounted concrete pump

The electrical control system adopts PLC, Omron, Mitsubishi, Schneider and other components, with a high degree of automation.
